FRAME
All New Series 3 6061 Aluminum Frame, 29” Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
FRONT SUSPENSION
Marzocchi Bomber Z1 29", Rail Damper with Sweep Adjustment, 140mm Travel, Kabolt Bolt-On Axle, 44mm Offset
REAR SUSPENSION
Fox Float X, Performance Series, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x55mm, M8x30mm Top, M8x25mm Bottom
RIMS
Marin Aluminum Double Wall, 29mm Inner, Sleeved Joint, Disc Specific, Tubeless Compatible
HUB, REAR
Forged Alloy, 148x12mm, Quad Sealed Bearings, Centerlock Disc, 32H, Standard Freehub Body
HUB, FRONT
Forged Alloy, 110x15mm, Disc, 32H
SPOKE, NIPPLES
14g Black Stainless Steel
TIRES
Maxxis Assegai, 29x2.5", MAXX TERRA, EXO, Tubeless Compatible
DERAILLEUR, REAR
Shimano XT, 12-Speed, SGS
DERAILLEUR, FRONT
-
SHIFT LEVER
Shimano SLX, 12-Speed, SL-7100R
CRANKSET
FSA GRID, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Mego EXO Spindle, Boost Spacing
BOTTOM BRACKET
Mego EXO 73mm BSA
CHAIN
KMC X-12 Silver and Black
CASSETTE
SunRace 12-speed, 11-51
BRAKE, FRONT
Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, Metallic Pads, 203mm Rotor
BRAKE, REAR
Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, Metallic Pads 180mm Rotor
BRAKE LEVERS
Shimano BL-M4100 Hydraulic Lever, I-Spec EV Compatible
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM
Marin 3D Forged Alloy, 35mm
GRIPS
Marin Grizzly Lock On
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 175mm Travel, 30.9mm
SADDLE
Marin Speed Concept
PEDALS
-
EXTRAS
Bolt-On Thru-Axle
